Description
● Kompatibel dengan sebagian besar sensor kawat getar dan sebagian sensor digital
● Akurasi tinggi, andal, dan mudah dikonfigurasi
● Ringkas, kokoh, tahan lama, tahan air, dan serbaguna
● Komunikasi nirkabel 4G/3G
● Mendukung hingga 5 sensor digital untuk satu saluran fisik, total hingga 40 sensor digital
● Deteksi status kerja instrumen dan kesalahan cerdas
● Memori SSD internal dapat menyimpan 65.536 pembacaan
● Suhu pengoperasian -40 ~ 85ºC
● Konsumsi daya rendah, jam kerja lebih lama (>10 hari @ laju pengambilan sampel 0,5 jam tanpa pengisian daya)
Specifications
| Type | LPWAN04/08 | |
| Processor | Cortex-M3 | |
| Channel | 4/8 | |
| Measurement | VW, Temperature, RS485 | |
| Measuring Range(Frequency) | 400Hz～3800Hz | |
| Measurement Accuracy(Frequency) | ±0.05Hz | |
| Frequency Resolution | 0.01Hz | |
| Temperature Sensor Type | Digital temperature sensor/Thermistor temperature sensor | |
| Measurement Range(Temperature) | -55℃~ 125℃/-20℃~ 150℃ | |
| Temperature Resolution | 0.01℃ | |
| Temperature Accuracy | ±0.5℃ | |
| Power Consumption | ≤1mA(Sleep mode） | |
| Battery Life | Without solar panel charging:10 days (@sampling peroid of 30min with 4*inclinometers, 4*vibrating wires sensors) | |
| Ultra-low Power Mode | Support sleep mode | |
| Power Monitoring | Voltage | |
| Power Supply | Solar Power + lithium battery , External power supply | |
| RS485 | Fully isolated RS485 | |
| Transmission | 4G full network communication | |
| Storage Capacity | 65535 Samples | |
| Self-diagnosis | Sensor status diagnosis, power failure diagnosis | |
| Power Protection | Anti-reverse connection/anti-overvoltage/anti-overcurrent | |
| Communication Interface | ESD anti-static/secondary surge protection | |
| Sensor Interface Protection | Surge protection | |
| Waterproof | IP65 | |
| Size(L*W*H) | 200*110*90 (mm) | |
| Temperature Range | -40-85℃ (excluding lithium battery) | |
| Installation | Magnetic suction, hoop, bolt | |
| Weight | 1.0kg |
