Description
LS225+N1500 adalah alat uji ketebalan pelapisan tipe split, yang terdiri dari host dan probe digital N1500. Alat ini mengadopsi prinsip induksi arus eddy dan memiliki akurasi serta pengulangan pengukuran yang sangat tinggi, sehingga sangat cocok untuk mengukur lapisan ultra-tipis dan berbagai benda kerja berukuran kecil serta material berbentuk khusus.
Parameter
LS225 Plating thickness tester host parameters
| Parameter | Value |
|---|---|
| Display | 240×160 dot matrix LCD |
| Power supply | 4pcs of 1.5V AAA alkaline battery |
| Operation temperaturerange | 0℃-50℃ |
| Storage temperaturerange | -20℃-60℃ |
| Host size | 148*76*26 mm (L*W*H) |
| Weight (include battery) | 194g |
N1500 probe parameters
| Parameter | Value |
|---|---|
| Measuring principle | Eddy current |
| Substrate | Non-ferromagnetic metal |
| Measuring range | 0.0-1500μm |
| Resolution | 0.1μm: 0μm – 99.9μm 1μm: 100μm – 999μm 0.01mm: 1.00mm – 1.50mm |
| Repeatability | ≤ ± (0.8%H+0.1μm) Test with fixture, H is the standard value |
| Accuracy | ≤±(2%H+0.3μm) after 5 points calibration, H is the standard value |
| Unit | μm / mil |
| Measuring interval | 0.8s |
| Minimum measuring area | Ø = 7mm |
| Minimum curvature | Convex:1.5mm / Concave:10mm |
| Minimum substrate thickness | 0.05mm |
| Calibration | Support zero reference adjustment and 1 to 5-points calibration |
| Probe size | 110*15 mm (Without connecting cable) |
| Probe weight | 81g |
