Description
Pengukur Iluminansi Spektrum LS330 adalah instrumen serbaguna yang dirancang dengan sensor spektral. Alat ini digunakan untuk mengukur iluminansi, indeks UV, frekuensi kedipan, deviasi standar pencocokan warna (SDCM), indeks rendering warna (CRI), suhu warna terkorelasi (CCT), rasio bahaya cahaya biru, suhu, dan kelembapan dalam berbagai skenario seperti pencahayaan lampu dan lentera, pencahayaan luar ruangan, pencahayaan rumah kaca, dan pencahayaan panggung. Instrumen ini juga dapat menampilkan kurva spektral, yang membantu mengidentifikasi jenis perlengkapan pencahayaan. Instrumen ini juga memiliki mode iluminasi tanaman, yang dirancang khusus untuk lingkungan pertumbuhan tanaman. Alat ini dapat secara akurat mengukur kerapatan fluks foton fotosintesis (PPFD), PPFD (Biru), PPFD (Hijau), PPFD (Merah), Kerapatan Fluks Foton Hasil (YPFD), klorofil-a, dan klorofil-b, membantu pengguna memahami dan mengoptimalkan manajemen cahaya selama proses penanaman dan meningkatkan efisiensi pertumbuhan tanaman. Alat ini cocok untuk berkebun di rumah, pabrik tanaman, rumah kaca, penelitian pertanian, pencahayaan tanaman, dan bidang lainnya.
Parameters
| Parameters | Value |
|---|---|
| Illuminance Wavelength Range | 400nm ~ 700nm |
| Illuminance Wavelength Interval | 10nm |
| Illuminance Measurement Range | 0 ~ 1000000Lux |
| Illuminance Resolution | 0.1Lux |
| Illuminance Measurement Accuracy | ≤±(3%H + 2 Lux) (H is the standard value, calibrated under CIE standard A light source) |
| Illuminance Unit Options | Lux (default), FC |
| Correlated Color Temperature Measurement Range | 1000 ~ 100000K |
| UV Index Measurement Range | 0.0 ~ 15.0 |
| Flicker Frequency Measurement Range | 10 ~ 500HZ |
| Temperature Measurement Accuracy | ±0.5℃ |
| Humidity Measurement Accuracy | ±4%RH |
| PPFD measurement range | 0 – 10000 μmol/m²/s |
| PPFD measurement accuracy | ≤±(5%H+0.5 μmol/m²/s) |
| PPFD (Blue) measurement range | 0 – 5000 μmol/m²/s |
| PPFD (Blue) measurement accuracy | ≤±(10%H+0.5 μmol/m²/s) |
| PPFD (Green) measurement range | 0 – 5000 μmol/m²/s |
| PPFD (Green) measurement accuracy | ≤±(10%H+0.5 μmol /m²/s) |
| PPFD (Red) measurement range | 0 – 5000 μmol/m²/s |
| PPFD (Red) measurement accuracy | ≤±(10%H+0.5 μmol /m²/s) |
| YPFD measurement range | 0 – 10000 μmol/m²/s |
| YPFD measurement accuracy | ≤±(5%H+0.5 μmol /m²/s) |
| Chlorophyll-a measurement range | 0 – 10000μW/cm² |
| Chlorophyll-a measurement accuracy | 1.≤±(10%H+0.5μW/cm²) |
| Chlorophyll-b measurement range | 0 – 10000μW/cm² |
| Chlorophyll-b measurement accuracy | ≤±(10%H+0.5μW/cm²) |
| Response Time | <0.7s |
| Test Aperture Diameter | Φ21mm |
| Size | Length 188.5mm Width 75.2mm Height 30.3mm |
| Weight | About 232g (including batteries) |
| Display | 240*160 Dot Matrix LCD |
| Power Supply | 2 AA Alkaline Batteries |
| Operating Environment | Temperature 0 ~ 40℃, Humidity <85%RH |
Features
Multi-parameter, wider application
In normal mode, the instrument measures parameters like illumination, CCT, flicker frequency, UV index, SDCM, CRI, temperature, and humidity to evaluate lighting characteristics. In plant mode, it accurately measures PPFD, YPFD, chlorophyll-a, and chlorophyll-b to optimize plant lighting for better quality and yield.
Freely switch between normal and plant modes
The instrument offers both normal and plant illumination modes, meeting diverse measurement needs. It handles both everyday lighting detection and plant growth parameters (e.g., PPFD, chlorophyll content), helping users optimize lighting in various scenarios.
High-precision spectral sensors
The instrument is designed with a spectral sensor, and the spectral response matches the V(λ) function. This ensures accurate measurement precision.
Flicker measurement, easily determine if lighting meets requirements
The instrument features a flicker measurement function, can evaluate whether lighting meets requirements based on flicker frequency and percent flicker. This provides reference for sales and R&D of lighting.
Accurately measure photosynthetic photon flux density (PPFD)
The instrument can accurately measure photosynthetic photon flux density (PPFD), yield photon flux density (YPFD) and chlorophyll content, providing comprehensive data support to help optimize plant light intensity, distribution and health status, and improve growth and yield.
High precision, pass authoritative metrology inspection
The instrument’s illuminance and color temperature measurements are ensured to pass authoritativeinspection.
Rich statistical functions
Simultaneously displays real-time, maximum, minimum, and average illuminance values.
Advanced digital probe technology
The instrument uses advanced digital probe technology, digital signal processing done directly at the probe.This reduces interference and provides excellent measurement accuracy.
