Description
The FS3150 solar film sales kit is designed to demonstrate the heat insulation, UV protection and reflective heat insulation effects of light-transmitting materials such as window film and heat insulation glass. It can directly show the blocking effect through the percentage data and the spinning speed of blades in the glass radiometer. The effect is intuitive and easy to understand.
The window film sales kit is equipped with ultraviolet flashlights and authentic Philips infrared lamps with adjustable light intensity, thus to simulate infrared and ultraviolet rays in outdoor sunlight respectively. The instrument is also equipped with a plexiglass booth and a special aluminum box for easy installation and packaging.
Packing
| No. | Product | Quantity | Unit |
|---|---|---|---|
| 1 | Plexiglass booth | 1 | pcs |
| 2 | 150W Philips infrared light | 1 | pcs |
| 3 | UV flashlight | 1 | pcs |
| 4 | LS123 UV power meter | 1 | pcs |
| 5 | Glass radiometer | 1 | pcs |
| 6 | LS122 IR power meter | 2 | pcs |
| 7 | Aluminum case dimension 46 * 39 * 20 cm(L * W * H) | 1 | pcs |
| 8 | User Manual | 1 | pcs |
| 9 | Certification card | 1 | pcs |
Features
After unpacking, please place the accessories according to the picture below. The name and function of each accessory are as follows. The serial number below corresponds to the serial number in the figure
Glass test slot
It can be used to fix materials such as heat insulation glass and stick-film glass. The width can be adjusted by screws (≤10mm)
Retractable UV flashlight
It is for simulating the ultraviolet rays of the sun, and achieves a concentrating effect by telescoping to adjust the UV intensity and supports USB charging
LS123 UV power meter
Measure the intensity of ultraviolet light passing through the material and calculate the ultraviolet rejection rate of the sample by using the data before and after the material is inserted
LS122 infrared power meter (opposite the infrared light)
Measure the intensity of infrared rays passing through the measured material and calculate the infrared rejection rate of the sample through the data before and after the material is inserted
