Description
LS125 adalah smart host yang dapat mendukung 12 probe berbeda. Host ini dapat mengidentifikasi berbagai probe secara cerdas. Host ini terhubung ke probe melalui konektor aviasi. Fungsi utama host ini adalah untuk menampilkan data uji. Host yang dilengkapi probe dapat digunakan untuk deteksi intensitas dan energi ultraviolet. Untuk menggunakan host ini, Anda perlu membeli probe yang sesuai untuk digunakan sesuai kebutuhan pengujian Anda.
Parameter
| Parameters | LS125 UV Light Meter |
|---|---|
| Weight | About 194g |
| Dimension | 148mm * 76mm * 26mm (L*W*H) |
| Display | 240*160 dot matrix LCD |
| Power Supply | 4 AAA alkaline batteries |
| Probe Connection | Push pull (Snap-in style)，Aviation socket |
Probe Selection
According to the spectral response range, application, measuring range and test aperture size of the light source, we have introduced 9 different types of probes (probe must be purchased separately). The selection table is as follows:
Select according to the spectral response range and application of the light source
| No. | Probetype | Spectral response range | Power range | Test aperture | Application | Link |
|---|---|---|---|---|---|---|
| 1 | UVC-X0 | 230-280nm | 0 – 200000 μW/cm² | Φ10mm | 254nm UV sterilization mercury lamp | More details |
| 2 | UVC-X2 | 210nm-250nm | 0 – 200000μW/cm² | Φ10mm | 222nm far UVC lamps | More details |
| 3 | UVCWP-X1 | 230-280nm | 0 – 200000 μW/cm² | Φ10mm | 254nm UV sterilization mercury lamp,waterproof | More details |
| 4 | UVCLED-X0 | 230-315nm | 0 – 200000 μW/cm² | Φ10mm | 260nm-285nm UV LED germicidal lamp | More details |
| 5 | UVB-X0 | 280-315nm | 0 – 200000 μW/cm² | Φ10mm | General UVB intensity and energy measurement | More details |
| 6 | UVA-X0 | 315-400nm | 0 – 2000 mW/cm² | Φ10mm | High pressure mercury lamp in UV curing industry | More details |
| 7 | UVA-X1 | 315-400nm | 0 – 200000 μW/cm² | Φ10mm | General UVA intensity and energy measurement | More details |
| 8 | UVA-X2 | 315nm-365nm | 0 – 200000μW/cm² | Φ10mm | 340nm UVA aging lamps | More details |
| 9 | UVALED-X0 | 340-420nm | 0 – 200000 mW/cm² | Φ10mm | Area light source of UV LED in UV curing industry | More details |
| 10 | UVALED-X1 | 340-420nm | 0 – 200000 mW/cm² | Φ1mm | Point light source of UV LED in UV curing industry | More details |
| 11 | UVALED-X3 | 340-420nm | 0 – 200000 μW/cm² | Φ10mm | General UVA+UVV LED, low power measuring range | More details |
| 12 | BL-X0 | 410nm-490nm | 0 – 2000mW/cm² | Φ10mm | 450nm blue light | More details |
Suggestion of Probes for Classic Industry Application
| No. | Application | Suggested Probe |
|---|---|---|
| 1 | Detect UV Aging Box | UVA-X1, UVB-X0, UVA-X2 |
| 2 | Detect Ambient Light and Sunlight | UVA-X1, UVB-X0 |
| 3 | Detect Welding Arc | UVA-X1, UVB-X0, UVC-X0 |
| 4 | Detect UV Light of Non-destructive Testing | UVA-X0 |
| 5 | Detect UV Nail Lamp | UVALED-X3 |
| 6 | Detect Plant Growth Lamp or Reptile Lamp | UVB-X0 |
| 7 | Detecting the 222nm Far UVC Lamps | UVC-X2 |
| 8 | Detecting the Medical Phototherapy Devices or LED Blue Therapy Light | BL-X0 |
