Description
Efek penekanan latar belakang yang kuat, independen dari latar belakang
Deteksi stabil bahkan saat latar belakangnya adalah objek berwarna terang dengan reflektivitas tinggi.
Deteksi mudah dan stabil terlepas dari warna objek
Mudah mengidentifikasi objek warna apa pun pada jarak yang sama dengan kinerja unggul.
Aplikasi berkecepatan tinggi dan berkinerja tinggi secara lebih luas
Waktu respons tinggi kurang dari 1 ms untuk kinerja kecepatan yang sangat baik
Products Lineup
Cable type
| Type | Appearances | Detection distance(mm) | Spot size(mm) | Output type | Model |
| Diffuse reflective |  |
 |
≤Ф5mm (distance 250mm) | NPN | LO-Z30N |
| PNP | LO-Z30P | ||||
|
 |
NPN | LO-Z60N | ||
| PNP | LO-Z60P | ||||
|
 |
NPN | LO-Z80N | ||
| PNP | LO-Z80P |
Relay type
| Type | Appearances | Detection distance(mm) | Spot size(mm) | Output type | Model |
| Diffuse reflective |  |
|
≤Ф5mm (distance 250mm) | NPN | LO-Z30CAN |
| PNP | LO-Z30CAP | ||||
|
|
NPN | LO-Z60CAN | ||
| PNP | LO-Z60CAP | ||||
|
|
NPN | LO-Z80CAN | ||
| PNP | LO-Z80CAP |
Products Specifications
Cable type
| Model | NPN | LO-Z30N | LO-Z60N | LO-Z80N |
| PNP | LO-Z30P | LO-Z60P | LO-Z80P | |
| Type | Diffuse reflective | |||
| Detection distance(mm) | 300 | 600 | 800 | |
| Setting Distance (mm) | 25~300 | 25~600 | 25~800 | |
| Minimum Detection Blind Zone | ≤40mm | |||
| Detection Mode | BGS function (background suppression function) | |||
| Light Source | Red laser semiconductor (with anti-jamming function) | |||
| Spot Size (mm) | ≤ Ф5mm (at a distance of 250mm) | |||
| Minimum Detected Objects | ≤ Ф5mm wire | |||
| Operating Voltage | DC24V (the operating voltage range includes DC24V) | |||
| Output Action | Normally open and normally closed adjustable (not limited to the knob to adjust or replace the wiring, etc.) | |||
| Current Consumption | 30mA Max. | |||
| Response Time | ≤ 10ms | |||
| Black and White Color Difference | ≤ 15% (at 250mm) | |||
| Sensitivity Adjustment | knob settings | |||
| Output Types | LIGHT-ON/DARK-ON ON/DARK-ON | |||
| Power Indicator | Power indicator, light on when power on | |||
| Motion Indicator | Motion indicator, used to distinguish the sensor detection status | |||
| Circuit Protection | Reverse connection protection, short-circuit protection | |||
| Protection Level | IP67 | |||
| Ambient Light | Incandescent 5000 lux and sunlight more than 10,000 lux scenarios supported | |||
| Ambient Temperature | -10°C~55°C | |||
| Relative Humidity | 35%RH-85%RH (no condensation) | |||
| Voltage Withstanding | AC1000V, 50/60Hz 1min | |||
| Impact Resistant | Acceleration 500m²/s (approx. 50G), 3 times in each direction of X, Y, and Z | |||
| Vibration Resistant | 10-55Hz Compound amplitude 1.5mm 2 times in each direction of X, Y, and Z | |||
| Material | Plastic case | |||
| Weight | approx. 59g | |||
Relay type
| Model | NPN | LO-Z30CAN | LO-Z60CAN | LO-Z80CAN |
| PNP | LO-Z30CAP | LO-Z60CAP | LO-Z80CAP | |
| Type | Diffuse reflective | |||
| Detection distance(mm) | 300 | 600 | 800 | |
| Setting Distance (mm) | 25~300 | 25~600 | 25~800 | |
| Minimum Detection Blind Zone | ≤40mm | |||
| Detection Mode | BGS function (background suppression function) | |||
| Light Source | Red laser semiconductor (with anti-jamming function) | |||
| Spot Size (mm) | ≤ Ф5mm (at a distance of 250mm) | |||
| Minimum Detected Objects | ≤ Ф5mm wire | |||
| Operating Voltage | DC24V (the operating voltage range includes DC24V) | |||
| Output Action | Normally open and normally closed adjustable (not limited to the knob to adjust or replace the wiring, etc.) | |||
| Current Consumption | 30mA Max. | |||
| Response Time | ≤ 10ms | |||
| Black and White Color Difference | ≤ 15% (at 250mm) | |||
| Sensitivity Adjustment | knob settings | |||
| Output Types | LIGHT-ON/DARK-ON ON/DARK-ON | |||
| Power Indicator | Power indicator, light on when power on | |||
| Motion Indicator | Motion indicator, used to distinguish the sensor detection status | |||
| Circuit Protection | Reverse connection protection, short-circuit protection | |||
| Protection Level | IP67 | |||
| Ambient Light | Incandescent 5000 lux and sunlight more than 10,000 lux scenarios supported | |||
| Ambient Temperature | -10°C~55°C | |||
| Relative Humidity | 35%RH-85%RH (no condensation) | |||
| Voltage Withstanding | AC1000V, 50/60Hz 1min | |||
| Impact Resistant | Acceleration 500m²/s (approx. 50G), 3 times in each direction of X, Y, and Z | |||
| Vibration Resistant | 10-55Hz Compound amplitude 1.5mm 2 times in each direction of X, Y, and Z | |||
| Material | Plastic case | |||
| Weight | approx. 59g | |||
