Description
Features – STS4
-
Tanpa pemrograman.
-
Desain modular yang kokoh.
-
Dapat diperluas hingga 1.000 kanal.
-
Sample rate hingga 250 Hz per kanal.
-
Quick-Connect terminal blocks untuk pemasangan sensor cepat.
-
Kompatibel dengan berbagai sensor pengujian struktural.
-
Mendukung berbagai opsi daya, termasuk DC dan PoE (Power over Ethernet).
-
Semua kanal dilindungi dari petir dan lonjakan arus.
Applications
-
Pengujian Laboratorium.
-
Pemantauan Struktural.
-
Pengumpulan data umum.
specifications – STS4 Data Acquisition
| MODEL | STS4-16-TE4 |
| Measurement Types: Analog Input Temperature Input |
Analog Single-ended or Differential 3KΩ NTC Thermistor |
| Maximum Sample Rate: Analog Input Temperature Input |
250 S/s ~1 S/s (non user adjustable) |
| Progra mmable Gain Settings | 11 |
| Analog to Digital Converter (ADC) | 24-bit ADC (Sigma delta) |
| Inputs & Outputs | |
| Input Channels | 16 |
| Thermistor Inputs | 16 |
| Serial communication | RS232/422/485 |
| Digital I/O | Isolated Digital In (to 24V), 2x Digital Out |
| Voltage Output | +15 Vdc @ 800 mA |
| Memory | |
| Internal MicroSD Memory | 8 GB |
| Excitation Voltages | |
| Vx (programmable) | +0 to +5 Vdc @ 20mA (per channel) |
| V+15 | +15 Vdc @ 200 mA (per group of 4) |
| Power | |
| DC Supply | +24 Vdc @ 2.0 Amp |
| Power over Ethernet | +24 Vdc Passive PoE @ 0.5 Amp |
| Communication | |
| Wireless | n/a |
| Ethernet | 10T-Base (TCP/IP) |
| Sensor Interface | |
| Connector | 8-pin spring loaded wire terminal |
| Intelliducer Support | No |
| Physical | |
| Protection | Dustproof |
| Size (W x L x H) | 6.2 x 9.6 x 2.13 in (157 x 243 x 54 mm) |
| Weight | 2.56 lb (1,165 g) |
| Operating Temperature | -40° to 185 °F (-40 to +85 °C) |
| Warranty | 12 Months |
