Description
Features
- Compatible with interchangeable Conductivity, CTD (conductivity/temperature/depth), and DO sensors (sold separately) – swap out sensors for different applications
- Bluetooth, for easy logger configuration and data offload
- Easy to deploy, fully submersible (MX801)
- Direct read for convenient data offload (MX802)
- Logger diameter is less than 2 inches
- Faster data offload via Bluetooth 5.0
- Water detect feature indicates when logger was out of the water (MX801)
- Barometric pressure sensor included (MX802)
- Connect two sensors to one logger to get measurements like salinity adjusted DO directly, with no need for post-processing
- Guided calibration ensures accurate data
- User-replaceable batteries
Specifications
MX801 and MX802
Operating Range: -40° to 50°C (-40° to 122°F), cannot be frozen in ice
Radio Power: 1 mW (0 dBm)
Transmission Range: Approximately 30.5 m (100 ft) line-of-sight
Wireless Data Standard: Bluetooth 5
Number of sensors that can be connected: 2
Maximum Cable Length: 120m (400 ft)
Logging Rate: 5 second to 18 hours
Logging Modes:
-
Fixed interval (normal or statistics), burst, or multiple intervals with up to 8 user-defined logging intervals and durations, with pause and repeat options
Start Modes: Immediate, next interval or date & time
Stop Modes: Memory full, never stop (overwrite oldest data), date & time, or after a set logging period
Water Detect: Events are logged when logger is submerged or removed from the water (MX801 only)
Time Accuracy: ±1 minute per month 0° to 50°C (32° to 122°F)
Battery: Four AA, 1.5 V lithium batteries, user replaceable
Battery Life:
-
With W-CTD or W-CT sensors: 2 years, typical with 1-minute logging interval or slowerWith W-DO sensor: 1-year, typical with 5-minute logging interval or slowerFaster logging or statistics sampling intervals, entering burst logging mode, excessive readouts, and remaining connected with the app will impact battery life
Memory: 730,000 measurements, divided between channels (4 Mbyte memory)
Data Download Time (with Bluetooth 5+ devices):
-
Full memory: Approximately 3.5 minutes120,000 measurements: 1 minuteMay take longer the farther the device is from the logger
Barometric Pressure (MX802 only)
Measurement & Calibrated Range: 66 to 107 kPa (9.6 to 15.5 psia), -20° to 50°C (-4° to 122°F)
Accuracy:
-
Typical error: ±0.2 kPa (0.029 psi)Maximum error: ±0.5 kPa (0.073 psi)
Resolution: <0.01 kPa (0.0015 psi)
Pressure Response Time: <1 second to 90% at a stable temperature
Contribution to Water Level Accuracy:
-
Typical error: ±0.075% FS, 0.3 cm (0.01 ft) waterMaximum error: ±0.15% FS, 0.6 cm (0.02 ft) water
MX801 & MX802 Specs, continued:
Dimensions:
-
Logger diameter: 4.14 cm (1.63 inches)Length without sensor: 20 cm (8 inches)Length with W-CTD sensor: 36 cm (14 inches)Length with W-CT sensor: 33 cm (13 inches)Mounting loop: 12.7 x 22.6 mm (0.5 x 0.89 inches)
Weight:
-
MX801 Logger Head Only224 g7.90 ozMX802 Logger Head Only226 g7.97 oz
Wetted Materials:
-
Logger: PVC housing with polyester film label, PET sensor connector end cap and mounting handle with EPDM and Buna-N O-rings, passivated 316 stainless steel hardware rated for use in saltwater; MX802 also has ePTFE ventCollar: HDPE, titanium screwsNote: logger should be mounted so that no metal parts of the logger are in contact with other metals
Depth/Environmental Rating:
-
MX801: IP68; waterproof to 100m (with sensor(s) attached)MX802: IP67, NEMA 6; Weatherproof (with cable or Termination Plug attached); this model is not waterproof
What’s in the box:
- HOBO MX801 or MX802 data logger
- Coupler
- 3/32” Allen wrench
