Description
Sensor Features
- Measurement range of -40° to 100°C (-40° to 212°F)
- High accuracy: ± 0.2°C ( ± 0.36°F)
- Stainless-steel sensor tip
- Sensor and cable rated for immersion in water or soil up to 50°C for up to 1 year
Wireless Features
- 900 MHz wireless mesh self-healing technology
- 450 to 600 meter (1,500 to 2,000 feet) wireless range and up to five hops
- Up to 50 wireless sensors or 336 data channels per HOBO RX station
- Simple button-push to join the HOBOnet wireless network
- Onboard memory to ensure no data loss
- Powered by rechargeable AA batteries and built-in solar panel
Specifications
Sensor
Measurement Range:
-
-40° to 100°C-40° to 212°F
Accuracy:
-
±0.25°C from -40° to 0°C (±0.45°F from -40° to 32°F)±0.20°C from 0° to 70°C (±0.36°F from 32° to 158°F)±0.25°C from 70° to 100°C (±0.45°F from 158° to 212°F)
Resolution:
-
0.02°C0.036°F
Drift: <0.01°C (0.018°F) per year
Response Time (typical, to 90% of change):
-
Without solar radiation shield: 2 minutes, 30 seconds in air moving 1 m/secWith RS3-B solar radiation shield: 5 minutes in air moving 1 m/sec
Wireless Mote
Operating Temperature Range:
-
-25° to 60°C (-13° to 140°F) with rechargeable batteries-40° to 70°C (-40° to 158°F) with lithium batteries
Radio Power: 12.6 mW (+11 dBm) non-adjustable
Transmission Range:
-
Reliable connection to 457.2 m (1,500 ft) line of sight at 1.8 m (6 ft) highReliable connection to 609.6 m (2,000 ft) line of sight at 3 m (10 ft) high
Wireless Data Standard: IEEE 802.15.4
Radio Operating Frequencies:
-
RXW-TMB-900: 904-924 MHzRXW-TMB-868: 866.5 MHzRXW-TMB-921: 921 MHzRXW-TMB-922: 916-924 MHz
Modulation Employed:
-
OQPSKOffset Quadrature Phase Shift Keying
Data Rate: Up to 250 kbps, non-adjustable
Duty Cycle: <1%
Maximum Number of Motes: Up to 50 wireless sensors or 336 data channels per one HOBO RX station
Logging Rate: 1 minute to 18 hours
Number of Data Channels: 2
Battery Type/Power Source:
-
Two AA 1.2 V rechargeable NiMH batteries powered by built-in solar panel or two AA 1.5 V lithium batteries for operating conditions of -40° to 70°C
Battery Life:
-
With NiMH batteries: Typical 3-5 years when operated in the temperature range -20° to 40°C (-4°F to 104°F) and positioned toward the sun (see Deployment and Mounting), operation outside this range will reduce the battery service lifeWith lithium batteries: 1 year, typical use
Memory: 16 MB
Dimensions:
-
Sensor: 5.3 x 33 mm (0.2 x 1.3 inches)Cable length: 5 m (16.4 ft)Mote: 16.2 x 8.59 x 4.14 cm (6.38 x 3.38 x 1.63 inches)
Weight:
-
Sensor and cable: 82.5 g (2.91 oz)Mote: 223 g (7.87 oz)
Materials:
-
Sensor: Stainless steel waterproof tipMote: PCPBT, silicone rubber seal
Environmental Rating:
-
Sensor and cable: Immersion in water up to 50°C (122°F) for 1 yearMote: IP67, NEMA 6
