Description
Features
Sensor Features
- Measurement range of -40° to 100°C (-40° to 212°F)
- High accuracy: ± 0.2°C ( ± 0.36°F)
- Stainless-steel sensor tip
Wireless Features
- 900 MHz wireless mesh self-healing technology
- 450 to 600 meter (1,500 to 2,000 feet) wireless range and up to five hops
- Up to 50 wireless sensors or 336 data channels per HOBO RX station
- Simple button-push to join the HOBOnet wireless network
- Onboard memory to ensure no data loss
- Powered by 2 user-replaceable lithium AA batteries
Specifications
Sensor
Measurement Range:
-
-40° to 100°C-40° to 212°F
Accuracy:
-
±0.25°C from -40° to 0°C (±0.45°F from -40° to 32°F)±0.20°C from 0° to 70°C (±0.36°F from 32° to 158°F)±0.25°C from 70° to 100°C (±0.45°F from 158° to 212°F)
Resolution:
-
0.02°C0.036°F
Drift: <0.01°C (0.018°F) per year
Response Time (typical, to 90% of change): 2 minutes, 30 seconds in air moving 1 m/sec
Wireless Mote
Operating Temperature Range:
-
-40° to 70°C-40° to 158°F
Radio Power: 12.6 mW (+11 dBm) non-adjustable
Transmission Range:
-
Reliable connection to 457.2 m (1,500 ft) line of sight at 1.8 m (6 ft) highReliable connection to 609.6 m (2,000 ft) line of sight at 3 m (10 ft) high
Wireless Data Standard: IEEE 802.15.4
Radio Operating Frequencies:
-
RXW-TMB-x-900: 904-924 MHzRXW-TMB-x-868: 866.5 MHzRXW-TMB-x-921: 921 MHzRXW-TMB-x-922: 916-924 MHz
Modulation Employed:
-
OQPSKOffset Quadrature Phase Shift Keying
Data Rate: Up to 250 kbps, non-adjustable
Duty Cycle: <1%
Maximum Number of Motes: Up to 50 wireless sensors or 336 data channels per one HOBO RX station
Logging Rate: 1 minute to 18 hours
Number of Data Channels: 2
Battery Type: Two AA 1.5 V lithium batteries
Battery Life: 1 year, typical use
Memory: 16 MB
Dimensions:
-
Sensor: 5.3 x 33 mm (0.2 x 1.3 inches)Cable length: 0.3 m (1 ft), RXW-TMB-1-xxx; 1.8 m (6 ft), RXW-TMB-6-xxxMote: 16.2 x 8.59 x 4.14 cm (6.38 x 3.38 x 1.63 inches)
Weight:
-
Sensor and cable: 7.6 g (0.27 oz), RXW-TMB-1-xxx; 35.2 g (1.24 oz), RXW-TMB-6-xxxMote: 223 g (7.87 oz)
Materials:
-
Sensor: Stainless steel waterproof tipMote: PCPBT, silicone rubber seal
Environmental Rating:
-
Sensor and cable: Immersion in water up to 50°C (122°F) for 1 yearMote: IP67, NEMA 6
What’s in the box
- HOBOnet Wireless Temperature Sensor
- Lithium batteries
- Zip ties
