Description
Antena Pemancar Tingkat Cairan Radar RKL-02 memancarkan pulsa gelombang mikro yang sempit, pulsa di ruang dengan kecepatan transmisi cahaya, bertemu di permukaan media yang diukur, sebagian energinya dipantulkan kembali, oleh antena yang sama. Menembakkan pulsa dan menerima interval pulsa dan antena ke permukaan media yang diukur sebanding dengan jarak, untuk menghitung jarak pada permukaan antena ke media yang diukur. Sensor level radar ini memberikan solusi terbaik untuk pengukuran level yang akurat dan andal. Apakah Anda memerlukan sensor level cairan radar untuk reservoir atau untuk aplikasi industri, pemancar level radar kami menawarkan keserbagunaan dan daya tahan yang tak tertandingi.
| Item | Technical specifications |
| Range |
10m,30m,50m,70m |
| Output | 4-20mA,RS485(MODBUS-RTU) |
| Supply Voltage | 12VDC,24VDC,220VAC |
| Process connection | G1_1/2,support flange |
| Working frequency | Range ＜30m：6.8GHz ， Range ＞30m＜70m：26GHz |
| Accuracy | 128*64LCD display resolution:1mm |
| Relay alarm | 250VAC/30VDC@5A Optional |
| Ingress Protection | IP67 |
| Medium temperature | -40℃~ +150℃ |
| Medium pressure | -100～100kPa |
| Operating Temperature | -40℃~ +85℃ |
| Housing material | Aluminum alloy |
| Antenna material | 304ss |
| Shock | 10m/s²@10～150Hz |
| Storage Condition | 10℃-50℃@20%-90%RH |
MOUNTING
Radar antenna launch microwave has a certain Angle, from the edge of the antenna to the surface between the measured medium, and launch a microwave beam radiation areas shall not be an obstacle.
In order to ensure that products meet the requirements of IP67 rating,please make sure:
The sealing head intact;
The cable is not damaged;
Ensure that the cable used in line with the requirements of electrical connection in the specification;
Before entering the electrical interface, the cable bending down, to ensure that water will not flow into the shell, as shown in;
Please tighten the cable seal head, see;
Please return the unused electrical interfaces to blind plugging plugging tight, see.
DIMENSION
PRODUCT DETAILS
PRODUCT APPLICATION
- Biodegradation
- Agricultural Irrigation
- Chemical
- Reservoir
- River Well
- Water Treatment
- Urban Sewage
