Alat Uji Segel Panas Heat Seal Tester HST-01

Description

HST-01 Heat Seal Tester menyegel spesimen untuk menentukan parameter segel film dasar,film laminasi, kertas pelapis dan film laminasi penyegelan panas lainnya sesuai dengan kebutuhan standar relatif. Parameter segel termasuk suhu segel panas, waktu tunggu, dan tekanan segel panas. Bahan segel panas yang memiliki titik leleh, stabilitas panas, fluiditas yang berbeda, dan ketebalan dapat menunjukkan berbagai sifat segel panas, yang menyebabkan teknik segel yang jelas berbeda.

CHARACTERISTICS

* Micro-computer control; LCD display;

* Manu interface, PVC operation board;

* P.I.D digital temperature control system:

* Underlying double cylinder simultaneous loop;

* Two test start mode of manual and foot pedal;

* Independent temperature control of the upper and lower heat seal head;

* Various heat seal surfaces made to order;

* Encapsulate even-temperature heating pipe by aluminum;

* Rapid insertion and separation heating pipe plug;

* Anti-scald design;

* RS232 port;

TECHNICAL INDEXES

Seal Temperature: room temperature~300ºC

Temperature Control Accuracy: ±0.2ºC

Dwell Time: 0.1s~999.9s

Dwell Pressure: 0.05MPa~0.7MPa

Seal Surface:330 mmx10 mm (also customize)

Heat Type: Single heat surface or double heat surface

Gas Source Pressure: 0.05MPa~0.7Mpa (Users prepare gas source themselves)

Gas Source Inlet: Ф6mmpolyurethane pipe

Power: AC 220V 50Hz

Net weight:43kg

STANDARDS

• ASTM F2029

CONFIGURATION

Standard:Mainframe, footswitch

Optional:micro-printer, micro-printer communication cable, software, communication cable.
