Description
LS116 light transmittance tester is a professional instrument for testing the light transmittance of uniform light-transmitting materials. It uses a parallel light path design and can also be used to detect large thickness materials with an accuracy of ± 1% which is to ensure passing the testing of the metrology Institute. Light transmittance is an important technical indicator of many optical products, such as glass, solar film, laminated glass, PC plastic, etc. The test principle of the light transmittance meter is to use a visible light source to illuminate the measured substance. The sensor detects the incident light intensity of the light source and the light intensity after passing through the measured substance. The ratio of the transmitted light intensity to the incident light intensity is transmitted. Rate, expressed as a percentage.
Application
The LS116 light transmittance meter can be used to test the light transmittance of glass products, solar films, laminated glass, coating materials, organic material panels and other materials. Suitable for display, production, quality inspection, inspection and other occasions.
LS116 tests film glass
LS116 tests large thickness double glazing
LS116 tests solar film
LS116 tests transpraent glass
Parameters
| Parameter | Value |
|---|---|
| Light source | 380nm-760nm full wavelength, in line with CIE photopic luminosity function |
| Measurement accuracy | ± 1% (colorless and uniform transparent materials) |
| Resolution | 0.001% (0% – 10%) 0.01% (10% – 100%) |
| Test sample thickness | Less than 100mm |
| Test sample diameter | 10mm |
| Display | 240 * 160 dot-matrixes LCD |
| Weight | about 622g (without battery) |
| Dimension | 148mm * 76mm * 26mm (L*W*H) |
| Power supply | 4 AAA alkaline dry battery |
Features
High resolution, high permeability samples can be measured
Adopt high-resolution acquisition chip, which can realize high-precision data acquisition, fast response and real-time dynamic calibration, high measurement accuracy and fast test speed. The instrument can measure high-transmittance samples. The transmittance measurement range is 0.001% -99.8%, and its resolution can reach 0.001%
Two measurement ways for flexible to use
Equipped with a fixed base, with two measurement methods, therefore it is suitable for testing on-site measurement of automobile front glass, and also suitable for fixed-point light transmission measurement such as a fixed station in a factory
Field measurement
Pedestal measurement
Qualifications and Standards
The LS116 light transmittance meter conform to the following standard:
JJF1225-2009 Calibration Specification for Transmittance Meter of Automobile
