Description
Sensor Debu RK300-02 menggunakan prinsip hamburan laser, mendeteksi adanya konsentrasi partikel debu di udara, minimum dapat mendeteksi partikel 1.0um, memiliki konsistensi dan stabilitas yang baik, sesuai dengan lingkungan penggunaan yang berbeda, ada tipe dalam ruangan dan tipe luar ruangan yang dapat dipilih.
| Item | Technical Specification |
| Sampling object | PM1.0, PM2.5, PM10 Concentration |
| Range | 0-1000ug/m3 |
| Accuracy | ±3%FS@25℃ |
| Supply | 5VDC,12-24VDC |
| Output | 4-20mA,0-5V,0-10V,RS485 |
| Power Consumption | <50mA@24V(4-20mA) |
| Warm Up Time | 3min |
| Response Time | <90s |
| Temperature Drift | ≤0.2%FS/℃ |
| Stability | <±2%fs |
| Repeatability | <±1%fs |
| Operating Temperature | -20℃-+50℃@15-80%RH |
| Storage | -40-60℃@20%-90%RH |
| Shell material | ABS |
DIMENSION & MOUNTING
- Indoor (Wall-mounted installation)
- Outdoor
PRODUCT DETAILS
PRODUCT APPLICATION
- Dust & Noise Monitoring On Cunstruction Site
- Daily Environmental Monitoring
