Sistem Uji Kelembaban & Getaran Suhu Baterai Battery Temperature Humidity & Vibration Test System

Sistem pengujian ini mengadopsi pengujian untuk produk luar angkasa, otomotif, peralatan dan instrumen listrik, material, pelapis dan bagian lain dalam kondisi suhu & kelembaban serta lingkungan getaran. Ini banyak digunakan untuk melakukan uji ketahanan lingkungan, uji pertumbuhan keandalan, uji kualifikasi keandalan, uji penerimaan keandalan produk, pengujian rutin, uji penyaringan tekanan lingkungan dan sebagainya.

Description

SPESIFIKASI RUANG IKLIM

Item Specification
Internal chamber dimension (W*D*H) 1000*1000*1000mm
External chamber dimension(W*D*H) 1200*3000*3800mm approx.
Temperature range -40 ℃~ 150℃
Temperature fluctuation ±0.5℃
Temperature uniformity 2℃
Cooling speed(temp. Range: 85C~-40C) 5℃/min in average; without loading
Heating speed(temp. Range: -40C~85C) 5℃/min in average; without loading










Humidity range

10~98%RH (please refer to the below humidity curve)



Humidity fluctuation ±3%RH
Internal chamber material SUS#304 stainless steel, mirror finished
External chamber material Stainless steel with paint spray
Cooling method Water-cooled


Controller

Programmable control temperature and humidity

Can set different parameter for cyclic test

Insulation material 50mm high density rigid Polyurethane foam


Heater

Explosion-proof type SUS#304 stainless steel fins radiator pipe

heater

Compressor German Bock compressor
Refrigerant Environmental friendly refrigerant R449A/R23
Temperature sensor PT-100 dry and wet bulb sensor
Observation window Tempered glass
Testing hole 2 units with diameter 100mm, for cable routing
Sample tray SUS#304 stainless steel, 2pcs




Safety protection device

Protection for leakage Over-temperature

Compressor over-voltage and overload

Heater short circuit



SPESIFIKASI STANDAR SISTEM GETARAN



Vibration Shaker
Max. Sine Force 3200Kg.f peak
Max. Random Force 3200Kg.f r.ms
Max. Shock Force 6400Kg.f peak
Frequency Range 2~3000Hz
Displacement (p-p) 51 mm
Max. Velocity 2m/s
Max. Table Acceleration 100g (without loading)
Armature Diameter 335mm
Effective Armature Mass 30kg
HE/ST screw dimension 17×M10
Max. Load Capacity 300kg
Magnetic Leakage <10gauss
Axial Vibration Isolation Frequency <2.5Hz
Power Three-phase, 380V, 50Hz
Machine dimension 845mm*790mm*840mm; without expander table
Vibration controller system
Controller Hardware No of input channels: 02 analogue channels ADC: 24-bit Resolution

No of output channels: 01 DAC: 24-bit Resolution

USB 2.0 communication port

Controller Software Modules Random Vibration (1-5000Hz), Sweep Sine Vibration (1-5000Hz), Classical Shock,

Resonance Search, Track and Dwell

and Self Calibration

Other accessory Test Computer: LENOVO M4500

Printer: HP 1020plus

Customer Responsibilities Installing all utilities where required, including connecting utilities to the equipment

Installation/rigging of equipment

Completing any necessary building alterations including roof penetrations

Customers responsible for any permits required by –

local/state government



MEJA SLIP HORIZONTAL & EXPANDER KEPALA VERTIKAL



SPESIFIKASI STANDAR

Expander
Expander Size 600*600mm
Material Aluminum alloy with hard anodized surface


Max. Work Frequency

Sine: 1000Hz

Random: 2000Hz

Weigh 32kg
Slip Table
Table Size 600*600mm
Material Aluminum alloy with hard anodized surface


Max. Work Frequency

Sine: 1000Hz

Random: 2000Hz

Weight 35kg
Note:

1. High pressure oil-film bearing is used for better uniformity.
