Description
| Rated capacities (Emax) | 50t | Temperature, compensated | -10°C-+40°C |
|---|---|---|---|
| Rated output | 2.0±0.002m V/V | Temperature, operating | -30 -+70°C |
| Accuracy class | C3 | Maximum safe overload | 120%F.S |
| Zero balance | ±1%F.S | Ultimate overload | 200%F.S |
| TC ZERO | ±0.02%F.S/10°C | Excitation, recommended | 10-12V DC |
| TC SPAN | ±0.02%F.S/10°C | Excitation, maximum | 15V DC |
| Input resistance | 750±10Ω | Protection class | IP68 |
| Output resistance | 702±3Ω | Construction | Alloy steel |
| Insulation resistance | ≥5000MΩ | Cable | Length: 16m |
| Diameter: Φ 6mm |
